New production batch of Tamiya 58583 Egress 2013


Length: 430mm. Image shows painted and assembled kit.

Back, and Ready to Take On Modern Day Competition
Tamiya is pleased to welcome back the Egress, successor to the famed Avante. The Avante was originally launched in 1988 and Tamiya took advantage of the experience and know-how garnered by the Tamiya Racing Factory (TRF; founded in 1989) team to make a racing version of the Avante: the Egress. It featured carbon fiber plates made of the material seen on hi-tech racing cars and aircraft, and employed racing parts such as ball diffs, high-capacity oil dampers, and lightweight titanium screws. Now, the shaft-driven Egress receives a makeover to bring it right up to date and unleash a whole new world of potential.

Durable shaft-driven 4WD chassis uses a range of carbon parts
This shaft-driven 4WD chassis features a longitudinally-positioned motor and full ball bearings, while carbon fiber upper and lower decks ensure that the model has superb strength. Re-designed front and rear ball differentials offer excellent reliability and easy maintenance, working in tandem with the built-in center one-way to provide sure-footed movement. The one-way bearing can be locked. Universal drive shafts feature the same design as those used in the current TRF series parts, in order to maximize power transmission and improve resistance to wear and tear. 4-wheel double wishbone suspension is supported by 4 oil dampers equipped with aluminum cylinders, while the front and rear of the model are fitted with stabilizers. Aluminum front uprights offer excellent reliability, and ball bearings in steering linkage arms combine with 2mm thick carbon fiber plate to offer a linear steering response. The Egress has been truly revamped across the board, and it also features a brushless motor.

Specifications
●Length: 430mm, Width: 243mm, Height: 157mm ●Wheelbase: 275mm ●Tread (Front & Rear): 200mm ●Carbon Fiber Double Deck Frame ●Shaft-Driven 4WD ●Polycarbonate Body and Undertray ●Front & Rear Ball Differentials + Center One-Way ●3-Piece Steering Tie Rod ●4-Wheel Double Wishbone Suspension ●Tire Width/Diameter: 32/88mm (Front), 40/88mm (Rear) ●High-Capacity Aluminum Cylinder Oil Dampers ●Gear Ratio: 8.25:1 (When using kit-included 22T pinion) ●Requires Type 540 Motor and Electronic Speed Controller (sold separately)

Separately Required Items
●Type 540 Motor ●Electronic Speed Controller (ESC) ●2-Channel R/C Unit with ESC　●Battery Pack & Charger ●R6/AA/UM3 batteries for transmitter

Assembly manual PDF

Created to conquer – The Tamiya VQS (2020)

Besides the Tamiya Avante, probably the most beautiful and most famous Tamiya 4WD buggy of the 80s, there were also three other buggies in this series of cars. We all know the Egress, as it was the last “expansion stage” of the Avante before the scepter was handed over to the “Top Force Evolution”.
The two “entry-level models” in the competition, the “Vanquish” and the “Avante 2001”, were somewhat in the shadows.
Both models were technically almost identical and should be suitable for entry into the rc racing competition.
The use of a plastic tub chassis kept costs down. The “Vanquish” in particular was able to shine visually.
And this one has now been reissued as “VQS”. Naming rights have probably forced Tamiya to change the name to “VQS”.
Nonetheless, one of the most beautiful Tamiya buggies of the late 80s era. This buggy combines a beautiful classic color scheme with a very modern futuristic styled body, as well as, given the Hotshot and Thundershot series of vehicles, much more modern technology.
The “new” VQS kit comes with a pre-painted body, which allows the inexperienced model maker in particular to complete the model much faster.
We are particularly pleased about the improvements Tamiya gave the “VQS”. CVD’s front and rear, as well as the aluminum milled steering knuckles at the front were taken over from the Avante and Egress. In addition, the buggy is practically completely equipped with ball-bearings. Only 6 small ball bearings still need to be added.
Tamiya also has made a very nice bonus for the “VQS”. The “VQS Hi Cap Damper Set 47455”. We all know and love these dampers from the 80s. Also suitable for many other cars of that time. We have also equipped our “VQS” with the new Hi Caps. Visually and technically a real pleasure.
Overall, we went the classic way with our example. A Tamiya Super Stock BZ brushed motor and the Tamiya Hi Torque Servo Saver complete the car.
As with every Tamiya car, building it was a real treat. And the builder is rewarded with a beautiful model after completion.
We at TamiyaBlog are very happy about this iconic re-release. A real beauty, the new Tamiya “VQS” (2020)

Many thanks to Dickie Tamiya and Tamico for providing us with the Tamiya “VQS” kit.

Tamiya RC Live – Tamiya Grand Prix All Japan Championship Strategy Story & Tamiya RC Car Grand Prix capture story



Tamiya Grand Prix All Japan Championship Strategy Story
・ Talk about how to capture each class (JJ class, M sports, ST class, etc.).


Tamiya RC Car Grand Prix capture story
・ I will talk about how to capture each class (Formula E, comical, rider, etc.)
We will also broadcast the race in which Maezumi participated.

Cast
Tamiya Satoshi Maezumi, Riku Sunahara

Building a Mystery (Machine) – Customizing the Tamiya Lunch Box 2005

After having so much fun, while building the latest Tamic Comical Models, a long time project was waiting to be completed.

One of the most iconic Tamiya cars ever. The Tamiya Lunch Box. Everyone loves it, and it´s still one of the most popular Vintage Tamiya RC Cars. The LB is also an absolutely perfect base for customizing projects. Years ago, we had the idea to build a replica of the famous “Mystery Machine”, well known from the classic “Scooby Doo” TV show.

For this project, we´ve collected some parts for quite some time.
Here is a list of parts, we used on this car:

  • 84343 Chassis Red Style CW-01
  • 84345 CW-01 D-Parts Under Guard Set Red
  • 84347 CW-01 C.V.A. Short Shock Unit Set II White Style
  • 53068 RS-540 Sport Tuned Motor – Black
  • 19335442 Midnight Pumpkin Metallic – Chrome wheels
  • Full Ball Bearing Set for Grasshopper/ Hornet/Lunch Box
  • Custom Made Mystery Machine Decals
  • R31 House Formula Kart Slick Tire

Tamiya TS-41 Coral Blue matches the orginal “Mystery Machine” Decal perfectly.

All in all, the Lunch Box came out great, and it´s now one of our all time favourites.
Enjoy!
